Pressure Map and Six-Axis Force, One Time Base
GaitMotus™ 3D Tactile Pressure Walkway
A 3D tactile pressure walkway that combines a pressure-distribution array and force plates in one, with an 800 mm test width and customizable length. Its high array density and sampling rate synchronize multi-dimensional kinetics in a single time base, capturing plantar pressure distribution together with six-axis forces and moments (Fx/Fy/Fz/Mx/My/Mz) for gait analysis and balance assessment and training. Low experiment cost and well-normalized data keep research datasets detailed and complete; it synchronizes with third-party kinematic, kinetic and physiological systems and exports raw data for research analysis.
- Array density
- 4 points/cm²
- Sensor count
- 76,800 / 115,200
Plantar Pressure Distribution
How the pressure array renders the footprint, its peak regions and the centre-of-pressure path.
- Peak pressure
- —
- Contact area
- —
- Left / right
- —
- COP
- —
Report charts
Charts of the kind this product’s reports and analysis screens contain, animated in step with the preview above; their values are illustrative too.
This preview animates software-generated illustrative values so the data the system produces can be understood. No physical device is connected and no reading here is a measurement.
Core Capabilities
The capability points below are taken from the official product material for this product.
8 / 12 six-axis force plates combined with a pressure-distribution array
2400 / 3600 × 800 mm test area
Unified time base synchronizes multi-dimensional kinetics
capturing plantar pressure and six-axis force/moment together
Syncs with third-party kinematic / kinetic / physiological devices
raw-data export
Test barefoot
shod, or with assistive devices across a wide range of scenarios
21 years of in-house R&D
ISO 13485 quality system; NMPA & CE registered
Typical Workflow
A generic research-lab sequence; mounting, synchronization and export details follow the official technical file.
Set up and calibrate
Position the equipment for the protocol and complete zeroing or calibration before the first trial.
Acquire in sync
Record with third-party kinematic, kinetic or physiological systems on one time base where the protocol requires it.
Process and analyze
Review trials in the analysis software and derive the metrics your study defines.
Export and publish
Export raw or processed data for statistics, modelling and publication.
Technical Specifications
| Parameter | Specification |
|---|---|
| Test area | 2400 × 800 mm / 3600 × 800 mm |
| Sensor type | Pressure array + 6-axis force plate |
| Array density | 4 points/cm² |
| Sensor count | 76,800 / 115,200 |
Application Scenarios
Application areas listed in the official product material.
- SCENARIO 01
Gait assessment
LAGRANGE3D TACTILE PRESSURE WALKWAYAL-500-G1-F - SCENARIO 02
Six-axis kinetics analysis
LAGRANGE3D TACTILE PRESSURE WALKWAYAL-500-G1-F - SCENARIO 03
Balance training (standing / sit-to-walk / gait)
LAGRANGE3D TACTILE PRESSURE WALKWAYAL-500-G1-F
Documentation
Datasheet preview and download; the official technical file governs final mechanical and electrical details.
- Datasheet · AL-500-G1-F
Ready to measure?
Tell us your protocol, subjects and lab layout — we will propose a configuration and a quote.
