Posture and Gait Screening in One Station
PelmaMotus™ Pro Movement Function Screening System
A movement-function screening system built on a distributed pressure-sensor array (4 points/cm², sampling up to 200 Hz, 16-bit ADC), with high-precision force sensors for real-time calibration. Paired with a biomechanics and rehabilitation knowledge base and AI analytics, it quickly captures standing posture and gait to generate assessment results and exercise-rehabilitation guidance — supporting risk screening and prevention with a comprehensive movement-function evaluation.
- Array density
- 4 points/cm²
- Sensor count
- 9,600
- Sampling frequency
- Up to 200 Hz
- Test area
- 400 × 600 mm
Plantar Pressure Distribution
How the pressure array renders the footprint, its peak regions and the centre-of-pressure path.
- Peak pressure
- —
- Contact area
- —
- Left / right
- —
- COP
- —
Report charts
Charts of the kind this product’s reports and analysis screens contain, animated in step with the preview above; their values are illustrative too.
This preview animates software-generated illustrative values so the data the system produces can be understood. No physical device is connected and no reading here is a measurement.
Core Capabilities
The capability points below are taken from the official product material for this product.
Closed-loop solution for health-check and rapid screening
static/dynamic plantar pressure yields balance/posture and single-leg gait/arch results with rehab guidance; a QR-linked mini-program serves tailored exercise plans (articles, videos) or refers users to the right department
High density
4 points/cm² across 9,600 pressure sensors, plus 4 high-precision single-axis force sensors for real-time calibration, addressing the linear force-output drift common to pure pressure sensors; national invention patent granted
600 mm extra-wide test area preserves a natural posture matching everyday standing or walking and reduces subjective interference for more objective data
Broad coverage across ages and occupational groups
High throughput
3-step guided workflow, two assessments in 70 seconds, about 200 people per day
Smart compute unit with cloud upload/download and large-scale data archiving and push for research analytics
Optional balance-training module for rehabilitation
improving patient balance
Typical Workflow
A generic screening sequence; the official product material governs test durations and report contents.
Register and guide
Create the subject record and follow the on-screen guidance through the test steps.
Test posture and gait
Run the standing-posture and gait tests on the pressure array.
Report and advice
Review the assessment result and the exercise-rehabilitation guidance it generates.
Follow up
Share the programme via the mini-program or refer to a clinical department; data archives in the cloud for later review.
Technical Specifications
| Parameter | Specification |
|---|---|
| Test area | 400 × 600 mm |
| Sensor type | Pressure array + high-precision force plate |
| Array density | 4 points/cm² |
| Sensor count | 9,600 |
| Sampling frequency | Up to 200 Hz |
| ADC resolution | 16-bit |
Application Scenarios
Application areas listed in the official product material.
- SCENARIO 01
Standing posture & balance
BAYESMOVEMENT SCREENING SYSTEMAL-600-G1 - SCENARIO 02
Single-leg gait
BAYESMOVEMENT SCREENING SYSTEMAL-600-G1 - SCENARIO 03
Balance training (optional)
BAYESMOVEMENT SCREENING SYSTEMAL-600-G1
Documentation
Datasheet preview and download; the official technical file governs final mechanical and electrical details.
- Datasheet · AL-600-G1
Ready to screen?
Tell us your setting — health check-up, community or campus — and the daily throughput you need; we will propose a configuration and a quote.
